Applications
TWS Bluetooth earbuds
TWS earbuds solution developed based on WUQI's high-end Bluetooth audio chip
Advantages
-
Supports dual-mode Bluetooth BT/BLE 5.3 protocol stacks.
-
Industry-leading RF performance: -98 dBm sensitivity @BR/EDR; TX power: 12 dBm.
-
Supports Hybrid ANC, and provides tools to support the R&D, debugging, production and testing of ANC.
-
Integrates 2 x Cap Touch for touch detection or in-ear detection.
-
Supports the 22nm process, and ultra-low power design with A2DP music current less than 3.7 mA.
-
Built-in HiFi 5 DSP with superb computing power.
-
Supports the solution of Multi-MIC ENC and AI noise reduction to achieve clear call experience in harsh environment.
-
Provides complete SDK and configuration tools to develop the TWS solution of ANC and ENC in a simplified and flexible way.
-
Adopted 4x6.4mm QFN packaging with simplified external circuit design.
-
Widely applied to TWS earbuds, stereo headphones, and Bluetooth speakers.
Block diagram
